LamiFIX® connector with M4 thread
from CHF 62.00
excl. VAT
You save
Zinc-plated connector LF 20.M4x7.5: plate 45 × 12 × 4 mm, M4 external thread 7.5 mm long. For use with suitable M4 threaded inserts and sleeves. Biscuit joiner setting 20.
LF 20.M4x7.5 connector with M4 thread
This zinc-plated LamiFIX® connector has a size 20 plate measuring 45 × 12 × 4 mm and an M4 × 7.5 mm metric external thread. It is designed for concealed shelf and furniture joints.
Compatible components and installation
The connector is used with suitable nylon or steel threaded inserts and M4 threaded sleeves. With the matching sleeves, it can be used in a 5 mm system-hole pattern. The M4 thread also allows connections to sheet metal, steel, aluminium and HPL.
Cut the plate slot with a biscuit joiner set to 20. The joint can be secured with a screw or bonded with assembly adhesive.
Additional information
| Weight | N/A |
|---|---|
| Pack size | |
| Thread | |
| Cam connector |
